The 408 in the Camaro broke a LS2 timing chain and took out 5 valves on 1 head a few months ago. I've removed a rotating assembly before, but never put one back together. I'm going to give this one a shot and hopefully it's not an epic fail. A few pistons picked up some valve dings but I'm going to re-use them. Since I'm reusing the pistons and rings I plan to open the ring gaps to .026 and .028 and put the pistons back to their original holes without honing the block. The oil pressure when it was running was lower than I like to see so I might as well attempt to freshen up the bottom while it's out. It's going back together with the following parts:

New bearings: Clevite H-Series Mains, ACL rods, Durabond cam
Weisco pistons
TSP h beam rods
TSP crank
Cloyes billet timing set with C5R chain
Melling high pressure pump
ARP studs
Aftermarket PRC LS3 257cc heads
LS9 gaskets
226/246 .629/.629 118+4
johnson lifters
TSP chromoly pushrods
TSP Billet oil restrictor

I also picked up a core 80e and bought the Jake's stage 5 kit along with their D321+ trans brake valve body. I'm planning to try a Pro Torque converter for the first time. I considered changing my boost source but after all the money spent on the fresh motor and transmission/converter I'm tired of spending money. The 3.6 kenne bell goes back on top but with a smaller pulley. Why don't we ever leave good enough alone? I could probably chunk this thing back together with a new oil pump, o ring, timing chain and let it eat with the same old 80e/pheonix converter and have a lot more money in my bank account.



That wouldn't stress you out while your telling yourself it's fun...




Seriously though, I have no idea why we do this ****. I don't have social media so I don't do it for internet fame like most do now. Lol



It's always been the horsepower adrenaline rush for me.

1970's social media was spontaneous interaction only



Only thing I don't like about that pic is he is sitting on his hood!! I assume it's his car, but damn that irritates my "pride in ownership" nerve

them ladies is mighty fine tho!



Wait a minute Red why do you have two feet in that photo of you?!?



I'd love to drive down and help jack that thing up. Putting a motor together is like a giant puzzle to me.



Its a Ford so its okay



all of my Fords have wrecked paint too. I still dont sit on the hoods lol



In for the epic winning !!!!



maybe I can get this engine to last more than a year before something else goes sideways. I Dropped a valve into it a year ago, now this...
